Salad Dressing Bottle Filling Machine Capping Machine CE Certification

Salad Dressing Bottle Filling Machine Capping Machine CE Certification





It is suitable for filling thick sauces with granules and high concentration in condiments, such as salad dressing, chili sauce, bean paste, peanut butter, sesame paste, jam, butter hot pot base, red oil hot pot base, etc. It is suitable for filling all kinds of sticky bodies and sauces containing all kinds of solid substances, such as pepper, peanut, meat, seasoning, and separating oil and seasoning into various containers. It is suitable for butter hot pot bottom, red oil hot pot bottom, chili sauce, honey juice, jam, etc.





The filling machine for thick thick sauce should be equipped with automatic mixing function for filling thick and granular sauce like materials. The structure is simple, the accuracy is high, and the operation is more simple. The filling valve is controlled by pneumatic valve, so the filling accuracy is higher. The filling volume and filling speed can be adjusted at will. The filling plug adopts anti drawing and lifting filling device.





Packaging materials: salad dressing, hot pot bottom material, viscous sauce, such as butter hot pot bottom material, chili sauce, honey, juice, etc.

Measurement method: piston pump volume measurement

Measurement range: 100-500g

Filling speed: 10 ~ 30 times / min

Filling accuracy: ± 1%

Total power: 0.75kw

Power supply voltage: 220 V / 50 Hz



According to the operation process can be divided into automatic filling machine and semi-automatic filling machine.



1. Semi automatic jam filling machine



1. The body is mainly made of high-quality stainless steel and aluminum alloy, with beautiful appearance, clean and sanitary, which fully meets the requirements of food hygiene;

Automatic jam filling production line

Automatic jam filling production line



2. It has the function of manual and automatic continuous filling, and the manual and automatic state can be quickly switched; it can be used with supporting conveyor line



3. It can be equipped with mixing, heat preservation and capping system to realize integrated operation



4. Quick and flexible connection makes disassembly and cleaning more convenient;



2. Automatic jam filling machine



The full-automatic jam filling machine can be equipped with bottle arranging and loading system, bottle washing system, drying and sterilization system, filling system, capping system, labeling and coding system.





Quick Detail:



1. Product: salad dressing filling machine

2. Capacity: 1000-3000bph

3. Suitable bottle: 200ml-2500ml

4. Authentication: ISO,CE,SGS





Description:



QS Series Auto-Spraying Type Bottle Washer
The equipment is mainly suitable for washing plastic bottle, glass bottle. It is washing way is rotary spraying construction. The machine can continuously automatic finish taking in and out rotating, washing, droping and so on.

GFP Series Negative Pressure Filler
The filling machine can fill liquid food which does not contain gas, such as all kinds viscousity materials, such as salad dressing, fruit jam filling (orange fruit jam, strawberry fruit jam, mango fruit jam), chocolate paste,peanut butter, honey, butter, Mayonnaise, ketchup etc. And all kinds of jam with small fruit pieces in it (size less than 3mm*3mm) filling in bottles. As the filler works in sealed condition and no pollution comes out. It is up to Foodstuff sanitation law. And it can accurately control liquid level, filling precision is high.





FXZ Series Screw Type Sealer
The sealer is for automatically sealing various sizes of bottle with plastic cap. It is perfect in performance, reliable in operation and easy in maintenance. So it is widely used in automatic packing lines for various kinds of wine, food, drink. Medicine and so on. It is one of the most ideal screw type automatic sealing equipment.





Applications:



This machine is specially made for all kinds of viscousity materials, such as salad dressing, fruit jam filling, chocolate paste,peanut butter, honey, butter, Mayonnaise, ketchup etc. And all kinds of jam with small fruit pieces in it (size less than 3mm*3mm) filling in bottles .This machine is our special design and enjoy good reputation in world market . All the contacted part with the filling material is high quality stainless steel.. The machine adopts piston pump for filling. By adjusting the position pump, it can fill all of the bottles in one filling machine, with quick speed and high precision.





Specifications:



No.	Items	Performance
01	Machine dimension (L×W×H)	2000mm×750mm×1500mm
02	No. of filling head	4/6/8/10/12/16
03	Suitable bottle size (abnormal bottles can also be valid)
	Diameter	Φ30mm~Φ100mm
	Height	50mm~250mm
04	Diameter of bottle mouth	≥φ18mm
05	Suitable filling range	200ml,400ml
06	Production capacity	400-3000 bottles/hour
07	Error range	±1%
08	Power supply	AC 220V; 50Hz
09	Power	1.5-4 Kw (power is twice than normal filler)
10	Pneumatic(air-operated)source	0.6 Mpa clean and stable compressed air







Competitive Advantage:



1. Adopts Piston pump & rotary valve with high filling accuracy

2. Filling nozzles is with drip-proof

3. Conveyor with photo sensor

4. PLC and Human-computer touch screen etc; no bottle, no filling
