12000BPH Craft Beer Filling Machine

Glass bottle Craft beer filling machine and crown capping machine 2-in-1 monoblock machine good quality CE

Beer is a kind of alcoholic beverage made from malt and malt as the main raw materials, with hops, through liquid gelatinization and saccharification, and then through liquid fermentation.

The automatic three in one beer filling machine glass bottle crown cap washing, filling and sealing unit is a new product developed on the basis of introducing, digesting and absorbing similar products at home and abroad and summarizing many years of production experience. The unit is a combination of washing, filling and sealing and driven by a drive motor (referred to as three in one equal pressure filling machine). It has the advantages of high degree of automation, compact structure, beautiful appearance, convenient operation and maintenance, safe and reliable, and continuous adjustable production capacity. It is an ideal production equipment for aerated drinks in China. It has a wide range of applications. According to the different bottle quality, shape and capacity of users, the design can be changed to meet the needs of production.

Features of glass bottle crown cover of automatic three in one beer filling machine:

The whole machine adopts the structure of suspended bottle clamping mouth conveyor, which makes the whole line conveying bottles more reliable. Different types of bottles only need to adjust the height of the conveyor belt and a small number of accessories to change the bottle type more quickly and labor-saving;

The filling machine adopts the principle of equal pressure filling, low temperature filling, high filling precision and adjustable liquid level; the glass bottle has a centering device.

The spring type flushing forceps can automatically turn the empty bottle 180 ° along with the track to flush, drain, and then automatically turn the bottle back to the right position. The flushing nozzle of this machine adopts plum shaped multi holes to fully flush the included angles of the bottom of the bottle, with high flushing efficiency;

The gland part adopts vibration motor cover adjuster. The gland is compact, the equipment structure is compact, the floor area is small, the process is flexible, and it is easy to operate and maintain. The capping head is made of ceramic capping film, which has high efficiency and does not damage the bottle cap.

The beer filling cylinder adopts annular cylinder with good pressure resistance. The filling valve adopts the special valve for Nanqing beer. Glass bottle beer is filled with vacuum twice, one before filling and one between filling and capping. The main purpose is to reduce the air in the bottle and integrate carbon dioxide as much as possible to ensure the taste of beer. In addition, according to the characteristics of the glass bottle, screw into the bottle, filling part of the cover, first to the center, valve down to fill, is conducive to the smooth operation of the whole glass bottle.

Because of the beautiful appearance and convenient opening, the crown cap or the pull ring cap is favored by the majority of consumers. The pull ring cap sealing machine produced by our company is stable and does not damage the cap, which is the high-quality choice of our customers!

The automatic beer bottle capping machine is mainly used for automatic capping of glass bottle crown cap, chrysanthemum cap and beer cap (such as beer, soda, sparkling wine, juice drink, health drink, sauce, vinegar, wine making industry, etc.). The equipment is easy to operate, easy to maintain, high automation intensity, reduce labor, reduce costs, production standards, is the ideal choice for the food industry.

Machine Description:

Beer is a fermented drink, because the beer dissolved a large amount of carbon dioxide gas, very easy to produce foam, and beer needs to minimize contact with oxygen to ensure its flavor. two technical requirements that must be met in the filling production process.

1 Minimize contact between beer and oxygen: Usually the filling process of glass bottle is to realize oxygen replacement by 2 times vacuum, vacuum the bottle before filling, then inject carbon dioxide gas to replace oxygen, because the carbon dioxide is more heavy then Oxygen, the remaining oxygen is extracted when vacuuming again.

For easy open cans filling, it is not possible to replace oxygen with a vacuum due to the characteristics of the packing material, so in order to minimize oxygen contact, it is common to use a direct purge replacement to fill the cans with carbon dioxide gas before sealing with the filling valve. Due to the special design of the valve body, when the cans are sealed with the valve body, it continues to inflate the CO2 gas, while another gas loop releases a portion of the gas directly and it relies on a large flow of carbon dioxide gas to replace oxygen, while increasing the loss of carbon dioxide, but it is the only reliable solution to the current filling technology.

Machine Charactors:

• Overlarge rotary support bearing
• Exact round tank, made of stainless steel, manufactured in CNC center.
• Center the bottle mouth to guarantee the fine filling.
• Floating-ball electron liquid level meter in the filling tank, the flux is controlled by the main inflow valve
• Valve Startup Mechanism
• Valve-shutting mechanism
• Cam Exhausting mechanism
• All the parts contact with the drinks is made of stainless steel. (SUS316 and SUS304)

Main technical parameters
