Place of Origin: | CHINA |
---|---|
Brand Name: | WORLDSUN |
Certification: | CE ISO |
Model Number: | TBJ |
Minimum Order Quantity: | 1 Set |
Price: | USD3000-30000/Set |
Packaging Details: | Shrink Pack and Wooden Box |
Delivery Time: | 20-30 Days |
Supply Ability: | 10 Sets per Month |
Material: | Stainless Steel 304 | Capacity: | 30000 Bottles/hour |
---|---|---|---|
Label Material: | PE PET | Label Shrink Type: | Steam / Electric |
Shrink Location: | Top Shrink | Weight: | 2000kg |
Dimension(l*w*h): | 1060*750*1700mm | Voltage: | 220V/380V Can Be Designed |
Application: | Beverage, Food, Chemical, Commodity | Driven Type: | Electric |
Type: | Labeling Machine | After-sales Service Provided: | Engineers Available To Service Machinery Overseas, Video Technical Support, Online Support |
Condition: | New | Packaging Type: | Bottles |
Warranty: | One Year | Function: | Labeling Machine |
Product Name: | Sleeve Labeling Machine | Power: | 3kw |
Processing Types: | Labeling Machine | Bottle Type: | PET, Glass Bottles, And Containers |
Automtaic shrink sleeve label applicator best quality in China
Label Shrink Oven
This high speed automatic top shrink sleeve labeling machine is a fully automatic intelligent packaging line integrating bottle feeding, bottle splitting, bottle labeling and shrinkage label functions. The true high speed, accurate positioning, manpower simplification and perfect packaging are the spirit of the equipment design. It is applicable to beverage and healthy food factories, and has the functions of beauty and easy cleaning and maintenance.
Technical features:
High speed stability, long service life: its unique dexterous, concise design is unique in the industry, this unique design provides a strong technical support for the high-speed operation of the machine.
The high speed top shrink sleeve labeling machine (shrink film machine) is a full cover stainless steel main machine, which is waterproof and does not rust. Adjustable cutter head: rotary cutting, double-sided blade, long service life. According to the characteristics of nested label, the mechanical structure, circuit design and intelligent control are improved to improve the production efficiency. It can meet the needs of major beverage manufacturers, reduce production costs and improve productivity for customers.
High speed top shrink sleeve labeling machine ensure long time high speed, full load operation without pressure; The synchronous bottle separator ensures stable and even bottle conveying, and ensures long-time efficient and stable operation.
Industry: fruit juice, tea drinks, dairy products, mineral water, purified water, sports drinks, condiments, sugar and wine, pharmaceutical, cosmetics, washing supplies and other food and beverage industry, daily necessities industry;
Bottle type: round bottle, square bottle, flat bottle, curved bottle, special-shaped bottle, cup, barrel, filling bottle, etc;
New driving device: four-wheel drive, automatic centering, four-wheel pressure balancing driving device, which achieves the purpose of smooth, stable and high-speed label delivery;
High speed top shrink sleeve labeling machine ensures long-time high-speed, full load operation without pressure;
Double tray design: reduce the time of changing standard, everything to meet the requirements of high speed;
Conveyor motor belt encoder: synchronous stepless belt adjustment, more stable at high speed;
Full cover 304 stainless steel main frame: waterproof, no rust, stable structure;
No replacement, no debugging tool holder, rotary cutter head: long service life, convenient and fast tool change, smooth and beautiful cutting surface;
Single machine synchronous 4-wheel drive 8-point positioning center guide post: label guidance is more stable, accurate and smooth;
Tail shaped label control electric eye frame: easy to adjust the label position, and higher film cutting precision;
Synchronous bottle separator: bottle conveying is stable and uniform, ensuring long-time efficient and stable work;
Single synchronous drive brush down: accurate shooting, no bias, no fly mark;
Bottle detection and label control electric eye: imported high-precision photoelectric sensor is adopted, with accurate label segmentation, no label blocking and missing;
The industry's first synchronous constant micro tension feeding frame: avoid label segmentation inaccuracy caused by spring resistance fluctuation;
The industry's first improved standard delivery driving group: to avoid the dislocation and blocking of standard delivery caused by the center offset and step asymmetry caused by sudden large torque during high-speed standard delivery;
Automatic high speed top shrink sleeve labeling machine can be equipped with independent feeding frame and free positioning frame.
We can design and make high speed top shrink sleeve labeling machine according to your label and bottles
The best quality in China
High speed top shrink sleeve labeling machine
high speed top shrink sleeve labeling machine label shrink oven
Product features:
Full cover stainless steel host: the whole host is waterproof and does not rust;
Adjustable cutter head: rotary cutting, double-sided blade, long service life;
Single positioning center guide post: more stable label guide;
Synchronous bottle separator: more stable bottle conveying;
Label brushing group: more accurate label setting accuracy;
Low maintenance cost of consumables;
The reciprocating cutter is designed with rigid body combination of mining mechanism, smooth action and double tool life.
Elastic selection of multi bottle type: round bottle, square bottle, oval bottle, etc., or bottle mouth or bottle body.
High speed top shrink sleeve labeling machine working principle:
When the push bottle electric eye finds that there are bottles coming and thinks it is necessary for continuous production, the bottle feeding screw starts to push the bottles (the function of the bottle feeding screw is to divide the bottles with unequal distance and equal initial speed) and the bottles enter the core unit of the marking system. When the marking electric eye senses that there are bottles coming, it immediately transmits the information to the control center PLC, And through PLC, four instructions are issued successively: label sending, positioning, label cutting, and label shooting. When the marking is finished, the labeling process of a bottle is completed, and then it enters the label sorting and shrinking unit.
Top label, Body label, Full body label
All according to your inquiry
High speed top shrink sleeve Labeling machine as one of the equipment with high technology content in the back stage packaging, the high-speed and stable performance, unique dexterous design and the safety mode of man-machine cooperation have been fully affirmed by the majority of customers. The application fields are: food, beverage and pharmaceutical industry, condiments, fruit juice, injection needle, milk, refined oil, etc.
1. High speed top shrink Sleeve labeling machine is suitable for fruit juice, tea drinks, dairy products, purified water, condiments, beer, sports drinks and other food and beverage industries of various bottle types. It not only has high accuracy of labeling position, but also can highlight the bottle and improve the bottle shape after shrinking.
2. High stable mechanical structure: the whole machine adopts stainless steel protective frame and aluminum alloy body frame, which is stable and free from rust.
3. Flexible selection of multi bottle type: round bottle, square bottle, elliptical bottle, etc., and bottle mouth or bottle body can be selected.
4. Unique synchronous cutter holder, within the specification range, no need to change cutter base. If the specifications need to be changed, it can be completed quickly in 5 minutes.
5. Wide range of application: suitable for food, beverage, cleaning supplies, medicine, wine bottles and other plastic bottles, glass bottles, PVC, pet, PS, cans and other containers.
6. High quality positioning accuracy: full mechanical transmission design, using forced sleeve standard, all kinds of film materials above 0.030mm film thickness are applicable, film material inner diameter range of 5-10 can be adjusted.
7. Low maintenance cost of consumables: This machine adopts low-cost disposable blade, which is easy to replace and low-cost.
8. Reliable after-sales service: spare parts are available at any time in the warehouse of various parts of the machine, and experienced engineers provide technical support for you.
9. The shape is exquisite and beautiful, the overall framework is solid, and it is more light and flexible in use.
10. Exclusive design of reciprocating cutter, rigid body combination of mining mechanism, smooth action and double tool life.
11. Simple central column positioning, easy to change specifications, easy to use by the operator, easy to understand and learn to control, and completely avoid the trouble of users.
12. Leading the industry in new structural design, the quality is more solid, which is not comparable to the existing domestic products.
13. The structure of the machine is simple and generous, which can ensure low failure rate and simple maintenance.
14. The whole series of safety protection frame of main body is designed with care.
The high speed top shrink film sleeve labeling machine is a full cover stainless steel main machine, which is waterproof and does not rust. Adjustable cutter head: rotary cutting, double-sided blade, long service life. According to the characteristics of nested label, the mechanical structure, circuit design and intelligent control are improved to improve the production efficiency. It can meet the needs of major beverage manufacturers, reduce production costs and improve productivity for customers.
Dual drive
The H-type design of the mechanism ensures the requirements of four-wheel drive, automatic centering and four-wheel pressure balance. Due to the design of equal speed ratio, the purpose of standard setting, smooth sending, stable operation and fast cutting is fully realized.
Applicable varieties
This shrink film sleeve lableing machine breaks through the traditional marking technology, it can set three to four kinds of marking varieties in one machine, only need to change the mold to achieve different varieties and models of marking. On the basis of the standard model, a higher configuration of servo motor is added. The conveyor line motor is equipped with encoder, and the whole line has automatic stepless speed regulation.
