Place of Origin: | China |
---|---|
Brand Name: | Worldsun |
Certification: | ISO,CE,SGS |
Model Number: | GFP |
Minimum Order Quantity: | 1 Set |
Price: | By order |
Packaging Details: | Wooden box |
Delivery Time: | 1-3 months |
Payment Terms: | L/C, T/T, Western Union |
Supply Ability: | 1 set 1-3 months |
Type: | Filling Machine | Voltage: | 220V/380V, By Order |
---|---|---|---|
Automatic Grade: | Automatic | Packaging Type: | Bottles |
After-sales Service Provided: | Engineers Availabel To Service Machinery Overseas, Online Support | Certification: | ISO9001, CE, ISO, CE |
Weight: | According To Machine Capacity | Driven Type: | Electric |
Dimension: | According To Machine Capacity | Application: | Thick Liquid Bottle Filling Machine |
Packaging Material: | Wooden Box | Condition: | New |
Warranty: | One Year | Power: | According To Machine Capacity |
Material: | Stainless Steel 304 / 316 | Capacity: | According To Your Inquiries |
Function: | Bottle Filling Capping Machine | ||
High Light: | SS304 Syrup Filling Machine,380V Bottle Filling Capping Machine,PLC Bottle Filling Capping Machine |
Automatic syrup bottling production line ce certification stainless steel 304
Quick Detail:
1. Automatic in all process
2. PLC control ,Touch screen
3. Easy to operated
Description:
1) This machine has compact structure, flawless control system, and is convenient to operate with high grade automatism
2) All the parts contacting the media are made of high quality stainless steel, able to bear corrosion and easily rinsed
3) Adopts high precision and high speed ration filling valve so that the oil level is exact with loss, ensuring high quality filling
4) The capping head has constant twisting movement, which ensures capping quality, without damaging caps
5) Adopts high efficiency cap tidying system, with flawless equipment for feeding caps and protecting
6) Needs only to change the pinwheel, bottle entering screw and arched board when changing bottle models, with simple and convenient operation
7) There is flawless equipment for overload protecting, which can protect effectively machine and operator safety
8) This machine adopts an electromotor with transducer adjusting speed, andis convenient to adjust productivity
9) All the main electric elements, transducer, photoelectric switch, near switch,and electric controlling valve are imported to ensure the high quality performance of the whole machine
10) The control system has functions for auto controlling of oil levels, checking and alarming for cap shortage, and team output counting
11) All pneumatic components elements are SMC Edible Oil Monobloc Filler Capper style Filling Machinery are designed to fill and seal small bottle edible/food oil
Main Performance parameter:
|
|||||||||||||||||||||||||||
Quick Detail:
1. Product: Motor oil filling machine
2. Capacity: 1000-3000bph
3. Suitable bottle: 200ml-2500ml
4. Authentication: ISO,CE,SGS
Description:
QS Series Auto-Spraying Type Bottle Washer
The equipment is mainly suitable for washing plastic bottle, glass bottle. It is washing way is rotary spraying construction. The machine can continuously automatic finish taking in and out rotating, washing, droping and so on.
GFP Series Negative Pressure Filler
The filling machine can fill liquid food which does not contain gas, such as all kinds viscousity materials, such as Motor oil, Chili sauce, Mayonnaise, fruit jam (orange fruit jam, strawberry fruit jam, mango fruit jam), chocolate paste,peanut butter, honey, butter, Mayonnaise, ketchup etc. And all kinds of jam with small fruit pieces in it (size less than 3mm*3mm) filling in bottles. As the filler works in sealed condition and no pollution comes out. It is up to Foodstuff sanitation law. And it can accurately control liquid level, filling precision is high.
FXZ Series Screw Type Sealer
The sealer is for automatically sealing various sizes of bottle with plastic cap. It is perfect in performance, reliable in operation and easy in maintenance. So it is widely used in automatic packing lines for various kinds of wine, food, drink. Medicine and so on. It is one of the most ideal screw type automatic sealing equipment.
Applications:
This machine is specially made for all kinds of viscousity materials, such as Motor oil, Chili sauce, Mayonnaise, fruit jam filling, chocolate paste,peanut butter, honey, butter, Mayonnaise, ketchup etc. And all kinds of jam with small fruit pieces in it (size less than 3mm*3mm) filling in bottles .This machine is our special design and enjoy good reputation in world market . All the contacted part with the filling material is high quality stainless steel.. The machine adopts piston pump for filling. By adjusting the position pump, it can fill all of the bottles in one filling machine, with quick speed and high precision.
Specifications:
No. | Items | Performance |
01 | Machine dimension (L×W×H) | 2000mm×750mm×1500mm |
02 | No. of filling head | 4/6/8/10/12/16 |
03 | Suitable bottle size (abnormal bottles can also be valid) | |
Diameter | Φ30mm~Φ100mm | |
Height | 50mm~250mm | |
04 | Diameter of bottle mouth | ≥φ18mm |
05 | Suitable filling range | 200ml,400ml |
06 | Production capacity | 400-3000 bottles/hour |
07 | Error range | ±1% |
08 | Power supply | AC 220V; 50Hz |
09 | Power |
1.5-4 Kw (power is twice than normal filler) |
10 | Pneumatic(air-operated)source | 0.6 Mpa clean and stable compressed air |
Competitive Advantage:
1. Adopts Piston pump & rotary valve with high filling accuracy
2. Filling nozzles is with drip-proof
3. Conveyor with photo sensor
4. PLC and Human-computer touch screen etc; no bottle, no filling
