WE ARE COMMITTED TO BUILD HIGH EFFICIENCY, ENERGY SAVING, AND HIGH QUALITY MACHINERIES!
| Place of Origin: | China |
|---|---|
| Brand Name: | Worldsun |
| Certification: | CE ISO |
| Model Number: | DCGF |
| Minimum Order Quantity: | 1 set |
| Price: | USD55000/set |
| Packaging Details: | Wooden box |
| Delivery Time: | 70 days |
| Payment Terms: | L/C, T/T, D/P |
| Supply Ability: | 50 sets/year |
| Production Capacity: | 18000 Bottles/hour 500ml | Material: | Stainless Steel 304/316 |
|---|---|---|---|
| Power: | 5kw | Operation: | PLC Controled Automatic System |
| Application: | Carbonated Beverage PET Bottle | Dimension: | 2500x1900x2200mm |
| Filling Liquid: | Tonic Water | Condition: | New |
| Bottle: | 150-2500ml | Warranty: | 2 Years |
18000BPH Tonic Water Filling Machine PET Bottle Glass Bottle Automatic Stainless Steel
Quinine water is a mixture of soda water, sugar, fruit extract and quinine. Also known as tonic water (English: tonic water, also known as Indian tonic water, tonic water) is a kind of soft bubble beverage, which uses quinine (also known as "cinchona cream") as the main flavoring, with a natural plant bitterness, and is often used to mix various cocktails with spirits.
Quinine water is also called tonic or tonic. It's soda water mixed with sugar, fruit extract and quinine. Now it is generally used as a bar liquor.
It mainly used for producing Carbonated beverage; since carbon dioxide gases(CO2) are pressurized to mix with liquids , the pressure throughout the filling system is typically 0.3 Mpa-0.6Mpa. and because CO2 is more stable at low temperatures, low temperatures increase the solubility of CO2 in water. To increase the amount of carbon dioxide dissolved in water, the beverage is usually mixed and filled at 0-5℃;and there are many other factors affecting CO2 content in carbonated beverages.
Main Parameters:
| Model | DCGF32/32/10 |
| Production capacity | 15000 bottles/hour 500ml |
| Bottle | Round PET bottle |
| Bottle diameter | 30-90mm |
| Bottle height | 150-320mm |
| Compressed air | 0.3-0.7Mpa |
| Rinsing pressure | 0.25Mpa |
| Total power | 6.2KW |
(1).To use the clamp to hang the bottle neck; to maintain the bottle shape and speed.
(2) .The parts in contact with the material are made of high quality stainless steel, no dead angles, easy to clean;
(3) .Using high-speed filling valve, the liquid level is accurating and there is no liquid leaking, to ensure correct filling;
(4) .The capping adopts advanced technology, the capping and sorting machine is installed at a lower position, and the cap is in a horizontal position to ensure the quality of the cap without damaging the caps;
(5 ).Equipped with a complete protection device to effectively protect the safety of equipment and operators;
(6) .The control system has the functions of production speed control, insufficient cover detection, self-stop of card bottle and production count;
The bottle rinsing is an alternative to the traditional cast iron material sprocket washer. It not only has a long flushing time,
but also greatly increases the production capacity.
The filling part adopts advanced micro-negative pressure gravity filling principle, which is fast, stable and accurate. Make sure the liquid level is accurate and free of liquid damage.
The capping part adopts the magnetic torque type capping head, and the capping head made of copper material can realize the function of grasping and screwing the cap quickly and accurately.
The host adopts advanced PLC automatic control technology, and the main electrical components and pneumatic components are world famous brand products.
