| Place of Origin: | China |
|---|---|
| Brand Name: | Worldsun |
| Certification: | CE, ISO, SGS, GMC |
| Model Number: | BGF |
| Minimum Order Quantity: | 1 Set |
| Price: | USD10000-30000 per Set |
| Packaging Details: | Shrink film and Wooden box |
| Delivery Time: | 3 Months |
| Payment Terms: | T/T, L/C, Western Union |
| Supply Ability: | 20 Sets per Year |
| Material: | Stainless Steel 304, 316, By Order | Automatic Grade: | Automatic, Semi-Automatic, By Order |
|---|---|---|---|
| Weight: | By Order | Driven Type: | Electric |
| Dimension: | By Order | Type: | Sauce Filling Machine |
| High Light: | 2000BPH Sauce Filling Machine,SUS304 Sauce Filling Machine,2000BPH sauce bottling machine |
||
Automatic caramel sauce filling machine,caramel sauce filler + capper machine
Purpose:
This Automatic peanut butter sauce filling machine capping machine is an automatic oil filling and capping machine, from bottle making to Sauce filling, capping, labeling and packing. Automatic sauce filling machine capping machine adopt vacuum filling type,it could be applicable for all kinds of liquid products filling and capping . no bottles no filling and capping,PLC control system,easy operation.
Quick Detail:
1. Control: PLC
2. driver: ELEC
3. material: SUS304
4. Productivity: 2000-18000bph
Description:
Automatic caramel sauce filling machine capping machine is suitable to fill and seal 100ml-5L spicy sauce, ketchup, oil bottles,cans of cooking oil,mustard oil,sunflower oil,refined oil,vegitable oil etc.
Online filler with cap sealing unit
Edible Oil Filling also suitable to fill 15Kg Mustard Oil Tins as optional choice
Applications:
Automatic ketchup tomato sauce filling machine capping machine is most commonly applicable for pharmaceutics, daily chemicals, foodstuffs, cosmetics, pesticides and other industrials.
Typical application: Cooking Oils,hot suce, Detergent,Sauce, Salad, Butter & Margarine, Ketchup, Jams, Cream, Honey, shampoos etc.
Technical Data:
| Model |
Number of washing filling and capping |
Production capacity Bottle per hour(0.5L) |
Applicable bottle specifications (mm) |
Power(kw) |
Dimension (mm) |
| GZS8/1 | 8, 1 | 2000 | 0.1L-5L D=50-108 mm H=170-340mm |
3.58 | 2100x1400x2300 |
| GZS16/6 | 12, 5 | 4000-5000 | 3.58 | 2460x1720x2350 | |
| GZS18/6 | 18, 6 | 6000-7000 | 4.68 | 2800x2100x2350 | |
| GZS24/8 | 24, 8 | 9000-10000 | 4.68 | 2900x2500x2350 | |
| GZS32/10 | 32, 10 | 12000-14000 | 6.58 | 3100x2800x2350 | |
| GZS40/12 | 40,12 | 15000-18000 | 6.58 | 3500x3100x2350 |
Competitive Advantage:
Main characteristics are as following:
1 Compact structure, complete controlling system, convenient operation and high automatization;
Parts connect with material are all made from good stainless steel, bear rust and easy cleaning.
2 Adopt with high accurate pisiton valve, precise in fix quantify and no dripping.
3, The filling amount adjustment adopts with round orbit. The gradient adjustment of round guiding orbit is convenient, which works stable and no impact.
4, The cap spinning head is adopted with constant wrest moment magnetism device, which ensures the quality of cap spinning and no damage to caps.
5, Adopts with high effect cap ordering system and complete cap feeding and protection device.
6, With perfect over loading protection device, it can protect the machine when the glass bottle is jammed in machine.
7, With frequency conversion timing motor, this machine can do proper adjustment to its production capacity.
8, It is equipped with eliminating structure for reverse caps and alarm system when no caps feeding.
9, Has the function of filling with bottles and no filling without bottles.
10, The electric system is the combine operation of HMI and button, easy to operate.
